DJ 12 LF 350

• 800 WContinuous power handling
• 3.0 in (76 mm)Voice coil diameter
• Ferrite Magnet material

Specifications

• Nominal diameter320 mm (12.0 in)
• Nominal impedance8 Ω
• Minimum impedance6.5 Ω
• Nominal power handling400 W
• Continuous power handling800 W
• Sensitivity (1W/1m)101.0 dB
• Frequency range50 – 3000 Hz
• Voice coil diameter 75.5 mm (3.0 in)
• Winding material Copper
• Former material Glass Fibre
• Winding depth 14 mm (0.55 in)
• Magnetic gap depth8 mm (0.31 in)
• Flux density1.4 T

Design

• Surround shape Double Roll
• Cone shape Radial
• Magnet material Ferrite
• Spider Single
• Pole design T-Pole

Parameters

• Fs 53 Hz
• Re 5.2 Ω
• Qes 0.2
• Qms 7.2
• Qts 0.19
• Vas 63.0 dm3 (2.2 ft3)
• Sd 522.0 cm2 (80.9 in2)
• η₀ 4.8 %
• Xmax 5.0 mm
• Xvar 7.0 mm
• Mms 54 g
• Bl 22.3 Txm
• Le 0.83 mH
• EBP 265 Hz

Mounting And Shipping Info

• Overall diameter 316 mm (12.4 in)
• Bolt circle diameter 296 mm (11.6 in)
• Baffle cutout diameter 282.0 mm (11.1 in)
• Depth 133 mm (5.24 in)
• Flange and gasket thickness 12 mm (0.49 in)
• Air volume occupied by driver 3.3 dm3 (0.12 ft3)
• Net weight 7.6 kg (16.7 lb)
